3.5mm PHONE JACK SMT TYPE-Gaudi Electronics Co., Ltd. - Technology connects the future, interconnect solutions, global leader

GD-PJS-3027HProduct specifications Rated power supply: 0.5A 30VDC Contact impedance: 30m Ω Insertion and extraction force: 3-20N Insertion and extraction times: 5000 times Welding type: SMD Pack……Detailed >>

PJ-WP30015DS SERIES

Waterproof type, 4 Pole, SMT type

PJ-WP30015DS SERIESRated power supply: 1A 12VDC Contact impedance：30mΩ Insertion and extraction force：6-20N Number of insertions and removals：5,000second Welding type：SMT TYPE Circuit: 4 poles Waterpro……Detailed >>

PJ-WP35383E SERIES

Waterproof type, 4 Pole, SMT type

PJ-WP35383E SERIESRated power supply: 1A 12VDC Contact impedance：30mΩ Insertion and extraction force：4-20N Number of insertions and removals：5,000second Welding type：SMT TYPE Circuit: 4 poles Waterpro……Detailed >>

PJ-WP35408E SERIES

Waterproof type, 4 Pole, SMT type

PJ-WP35408E SERIESRated power supply: 1A 12VDC Contact impedance：30mΩ Insertion and extraction force：3-30N Number of insertions and removals：5,000second Welding type：DIP TYPE Circuit: 3 poles Waterpro……Detailed >>

PJ-WP35434C SERIES

Waterproof, 3 Pole, DIP Type

PJ-WP35434C SERIESRated power supply: 1A 12VDC Contact impedance：100mΩ Contact point: 5 poles Insertion and extraction force：3-30N Number of insertions and removals：5,000second Welding type：SMT Packag……Detailed >>

PJ-S53062 SERIES

5 Pole, SMT TYPE ,H:4.5mm

PJ-S53062 SERIESRated power supply: 0.5A 12VDC Contact impedance：50mΩ Insertion and extraction force：3-30N Number of insertions and removals：5,000second Welding type：SMT Packaging method：800PCS/REELDetailed >>

PJ-30266-61 SERIES

6.4 * 12 * 4mm/flat socket, 4 Pole SMT

PJ-30266-61 SERIESRated power supply: 0.5A 30VDC Contact impedance：30mΩ Insertion and extraction force：3-30N Number of insertions and removals：5,000second Welding typeSMT sinking board/board height H: 2.25m……Detailed >>

PJ-S3178 SERIES

6.3*12*2.25mm/SMT Sinking board H:2.25mm ,4 Pole

PJ-S3178 SERIESRated power supply: 1A 0.5VDC Contact impedance：30mΩ Insertion and extraction force：3-20N Number of insertions and removals：5,000second Welding type：SMT Packaging method：1,000PCS/REELDetailed >>

PJ-S3142C SERIES

6.3 * 14 * 4.5mm/Front Insert Board SMT Type

PJ-S3142C SERIESRated power supply: 0.5A 30VDC Contact impedance：30mΩ Insertion and extraction force：3-30N Number of insertions and removals：5,000second Welding type：SMT Packaging method: PCS/ReelDetailed >>

PJ-S3142XS SERIES

6.3 * 12 * 4.5mm/Flat socket, 4 Pole

PJ-S3142XS SERIESRated power supply: 0.5A 30VDC Contact impedance：30mΩ Insertion and extraction force：3-20N Number of insertions and removals：5,000second Welding type：SMT Packaging method：PCS/REELDetailed >>

PJ-S3127C SERIES

6.0*14.0*5.1mm/3 Pole

PJ-S3127C SERIESRated power supply: 0.5A 30VDC Contact impedance：30mΩ Insertion and extraction force：3-20N Number of insertions and removals：5,000second Welding type：SMT Packaging method：800PCS/REELDetailed >>

PJ-S3127 SERIES

6.3*14.0*4.4mm/3 Pole

PJ-S3127 SERIESRated power supply: 0.5A 30VDC Contact impedance：30mΩ Insertion and extraction force：3-20N Number of insertions and removals：5,000second Welding typeSMT/sinking board, board height: 2.6mm ……Detailed >>

PJ-S3118 SERIES

Flat socket/gold-plated feet/4 Pole sinking board H: 2.6

PJ-S3118 SERIESRated power supply: 0.5A 30VDC Contact impedance：30mΩ Insertion and extraction force：3-20N Number of insertions and removals：5,000second Welding typeSMT sinking board height H: 1.05mm P……Detailed >>

PJ-S3112A1 SERIES

4 Pole/Sinking board H:1.05mm

PJ-S3112A1 SERIESRated power supply: 1A 30VDC Contact impedance：30mΩ Insertion and extraction force：3-20N Number of insertions and removals：5,000second Welding type：SMT Packaging method：800PCS/REELDetailed >>

PJ-S3027E SERIES

6.5*14.0*5.0mm/4 Pole

PJ-S3027E SERIESRated power supply: 0.5A 30VDC Contact impedance：30mΩ Insertion and extraction force：3-20N Number of insertions and removals：5,000second Welding type：SMT Packaging method：800PCS/REELDetailed >>

PJ-S3020D SERIES

6.0*14.0*5.0mm/4 Pole

PJ-S3020D SERIESRated power supply: 1A 30VDC Contact impedance：30mΩ Insertion and extraction force：3-20N Number of insertions and removals：5,000second Welding type：SMT Packaging method：PCS/REELDetailed >>

PJ-S3020DS SERIES

6.0*14.0*5.0mm/4 Pole

PJ-S3020DS SERIESRated power supply: 1.0A 12VDC Contact impedance：50mΩ Insertion and extraction force：3-30N Number of insertions and removals：5,000second Welding typeSMT board height H: 4.5 Regarding th……Detailed >>

PJ-S53061 SERIES

5 Pole H:4.5

PJ-S53061 SERIESRated power supply: 1A 30VDC Contact impedance：30mΩ Insertion and extraction force：3-20N Number of insertions and removals：5,000second Welding type：SMT Packaging method：900PCS/REELDetailed >>

PJ-S3013E SERIES

6.2*17.1*5.0mm/4 Pole

PJ-S3013E SERIESRated power supply: 0.5A 30VDC Contact impedance：30mΩ Insertion and extraction force：3-20N Number of insertions and removals：5,000second Welding type：SMT Packaging method：PCS/REELDetailed >>

PJ-S3022 SERIES

7.0*15.0*6.0mm/4 Pole

PJ-S3022 SERIESRated power supply: 0.5A 30VDC Contact impedance：30mΩ Insertion and extraction force：3-30N Number of insertions and removals：5,000second Welding type：SMT Packaging method：PCS/REELDetailed >>

PJ-S3212A SERIES

7.4*14.4*6.0mm/4 Pole

PJ-S3212A SERIESRated power supply: 1.0A 30VDC Contact impedance：30mΩ Insertion and extraction force：3-30N Number of insertions and removals：5,000second Welding type：SMT Packaging method：PCS/REELDetailed >>

PJ-S3214 SERIES

6.7*12.5*4.6mm/4 Pole

PJ-S3214 SERIESRated power supply: 1.0A 12VDC Contact impedance：30mΩ Insertion and extraction force：3-30N Number of insertions and removals：5,000second Welding type：SMT Packaging method：PCS/REELDetailed >>

PJ-S3507DSERIES

10.1*13.0*4.0mm/4 Pole

PJ-S3507DSERIESRated power supply: 0.5A 30VDC Contact impedance：50mΩ Insertion and extraction force：3-30N Number of insertions and removals：5,000second Welding type：SMT Packaging method: PCS/ReelDetailed >>

PJ-S3R2A7 SERIES

10.95 * 14.15 * 4.9mm/Flat socket, 4 Pole

PJ-S3R2A7 SERIESRated power supply: 1.0A 30VDC Contact impedance：30mΩ Insertion and extraction force：3-30N Number of insertions and removals：5,000second Welding type：SMT Packaging method：PCS/REELDetailed >>

PJ-S3246 SERIES

6.3*12.0*3.9mm/4 Pole

PJ-S3246 SERIESRated power supply: 1.0A 5VDC Contact impedance：50mΩ Insertion and extraction force：3-30N Number of insertions and removals：5,000second Welding type：SMT Packaging method：PCS/REELDetailed >>

PJ-S3R4A7 SERIES

10.95*15.55*4.9mm/4 Pole

PJ-S3R4A7 SERIESRated power supply: 0.5A 5VDC Contact impedance：70mΩ Insertion and extraction force：3-30N Number of insertions and removals：5,000second Welding type：SMT Packaging method：PCS/REELDetailed >>

PJ-S32339 SERIES

6.8*13.5*4.35mm/4 Pole

PJ-S32339 SERIESRated power supply: 0.5A 5VDC Contact impedance：70mΩ Insertion and extraction force：3-30N Number of insertions and removals：5,000second Welding type：SMT Packaging method：PCS/REELDetailed >>

PJ-S32338 SERIES

6.8*14.0*4.35mm/4 Pole

PJ-S32338 SERIESRated power supply: 0.5A 12VDC Contact impedance：50mΩ Insertion and extraction force：3-30N Number of insertions and removals：5,000second Welding typeSMT/sinking board, board H: 1.2mm Pa……Detailed >>

PJ-0238-xx SERIES

Flat socket/3 Pole sinking board H: 1.2

PJ-0238-xx SERIESRated power supply: 0.5A 30V DC Contact impedance：30mΩ Insertion and extraction force：3-30N Number of insertions and removals：5,000second Welding type：SMT Packaging method：PCS/REELDetailed >>

PJ-S32304A SERIES

7.7*12.6*4.6mm/4 Pole

PJ-S32304A SERIESRated power supply: 0.5A 30VDC Contact impedance：30mΩ Insertion and extraction force：3-30N Number of insertions and removals：5,000second Welding type：SMT Packaging method：800PCS/REELDetailed >>

PJ-367xD SERIES

Gold plated feet/3 Pole

PJ-367xD SERIESRated power supply: 0.5A 30VDC Contact impedance：30mΩ Insertion and extraction force：3-30N Number of insertions and removals：5,000second Welding type：SMT Packaging method：900PCS/REELDetailed >>

PJ-369x SERIES

6.0*17.0*5.0mm/3 Pole

PJ-369x SERIESRated power supply: 0.5A 30VDC Contact impedance：30mΩ Insertion and extraction force：3-20N Number of insertions and removals：5,000second Welding type：SMT Packaging method：600PCS/ReelDetailed >>

PJ-3733D SERIES

6.5*14.0*5.0mm/3 Pole

PJ-3733D SERIESRated power supply: 1A 30VDC Contact impedance：30mΩ Insertion and extraction force：3-20N Number of insertions and removals：5,000second Welding type：SMT Circuit: 4 poles Packaging met……Detailed >>

PJ-375x SERIES

6.0*17.0*5.0mm/4 Pole

PJ-375x SERIESRated power supply: 1A 30VDC Contact impedance：30mΩ Insertion and extraction force：3-30N Number of insertions and removals：5,000second Welding type：SMT Circuit: 5 poles Packaging met……Detailed >>

PJ-382xD SERIES

7.4*17.0*5.1mm/5 Pole

PJ-382xD SERIESRated power supply: 0.5A 30VDC Contact impedance：30mΩ Insertion and extraction force：3-30N Number of insertions and removals：5,000second Welding type：SMT Circuit: 3 poles Packaging m……Detailed >>

PJ-385xD SERIES

6.0*14.0*4.4mm/3 Pole

PJ-385xD SERIESRated power supply: 1A 30VDC Contact impedance：30mΩ Insertion and extraction force：3-20N Number of insertions and removals：5,000second Welding type：SMT Circuit: 3 poles Packaging met……Detailed >>

PJ-386xD SERIES

6.0*14.0*4.4mm/3 Pole

PJ-386xD SERIESRated power supply: 1A 30VDC Contact impedance：30mΩ Insertion and extraction force：3-20N Number of insertions and removals：5,000second Welding type：SMT Circuit: 4 poles Packaging met……Detailed >>

PJ-389xD SERIES

6.3*14.0*4.5mm/4 Pole

PJ-389xD SERIESRated power supply: 0.5A 30VDC Contact impedance：30mΩ Insertion and extraction force：3-30N Number of insertions and removals：5,000second Welding type：SMT Circuit: 4 poles Packaging m……Detailed >>

PJ-3917D SERIES

Gold plated feet/4 Pole

PJ-3917D SERIESRated power supply: 1A 30VDC Contact impedance：30mΩ Insertion and extraction force：3-20N Number of insertions and removals：5,000second Welding type：SMT Circuit: 4 poles Packaging met……Detailed >>

PJ-3956D SERIES

6.3*14.0*4.0mm/4 Pole

PJ-3956D SERIESRated power supply: 0.5A 30VDC Contact impedance：30mΩ Insertion and extraction force：3-20N Number of insertions and removals：5,000second Welding typeSMT/sinking board, board height: 2.05mm……Detailed >>

PJ-5055D SERIES

Sink plate H 2.05mm/3Pole

PJ-5055D SERIESRated power supply: 1A 12VDC Contact impedance：50mΩ Insertion and extraction force：3-23N Number of insertions and removals：5,000second Welding typeSMT sinking board/board height H: 2.1mm ……Detailed >>

PJ-5356D SERIES

Sink plate H: 2.1mm/4 Pole

PJ-5356D SERIESRated power supply: 1.0A 12VDC Contact impedance：50mΩ Insertion and extraction force：3-30N Number of insertions and removals：5,000second Welding type：SMT Circuit: 4 poles Packaging m……Detailed >>

PJ-5416D SERIES

6.8*13.3*4.45mm/4 Pole

PJ-5416D SERIESRated power supply: 0.5A 5VDC Contact impedance：70mΩ Insertion and extraction force：3-20N Number of insertions and removals：5,000second Welding type：SMT Packaging method：PCS/REELDetailed >>

PJ-T32338 SERIES

6.8*14.0*4.25mm/4 Pole

PJ-T32338 SERIESRated power supply: 1.0A 5VDC Contact impedance：30mΩ Insertion and extraction force：3-30N Number of insertions and removals：5,000second Welding type：SMT Packaging method：PCS/REELDetailed >>

PJ-T3523 SERIES

6.3*12.45*4.0mm/4 Pole

PJ-T3523 SERIESRated power supply: 1.0A 5VDC Contact impedance：50mΩ Insertion and extraction force：3-30N Number of insertions and removals：5,000second Welding type：SMT Packaging method：PCS/REELDetailed >>

PJ-T3R3A SERIES

10.95*14.15*4.9mm/4 Pole

PJ-T3R3A SERIESRated power supply: 1.0A 5VDC Contact impedance：50mΩ Insertion and extraction force：3-30N Number of insertions and removals：5,000second Welding type：SMT Packaging method：PCS/REELDetailed >>

PJ-T3R8A SERIES

10.95*13.95*4.9mm/4 Pole

PJ-T3R8A SERIESRated power supply: 1.0A 12VDC Contact impedance：100mΩ Insertion and extraction force：3-30N Number of insertions and removals：5,000second Welding type：SMT Packaging method：PCS/REELDetailed >>

PJ-T53063 SERIES

6.7*14.00*4.1mm/4 Pole

PJ-T53063 SERIESRated power supply: 05A 30VDC Contact impedance：50mΩ Insertion and extraction force：3-30N Number of insertions and removals：5,000second Welding type：SMT Packaging method：PCS/REELDetailed >>

PJ-T52309B SERIES

9.7*13.00*4.3mm/4 Pole

PJ-T52309B SERIESRated power supply: 05A 30VDC Contact impedance：50mΩ Insertion and extraction force：3-30N Number of insertions and removals：5,000second Welding type：SMT Packaging method：PCS/REELDetailed >>
